North American T-6 Harvard


North American AT-6C Harvard IIA, click to open in large format
1517
North American AT-6C Harvard IIA
c/n 88-14544 ex-USAAF 41-33846 ex-ZAF 7430

Canadian Car & Foundry T-6J Texan, click to open in large format Canadian Car & Foundry T-6J Texan, click to open in large format Canadian Car & Foundry T-6J Texan, click to open in large format
1675 - Original registration 1774
Canadian Car & Foundry T-6J Texan - C/n CCF4-486
ex-USAAF 52-8565 ex-Luftwaffe BF+079

Canadian Car & Foundry Harvard Mk.4, click to open in large format Canadian Car & Foundry Harvard Mk.4, click to open in large format Canadian Car & Foundry Harvard Mk.4, click to open in large format
Canadian Car & Foundry Harvard Mk.4, click to open in large format Canadian Car & Foundry Harvard Mk.4, click to open in large format Canadian Car & Foundry Harvard Mk.4, click to open in large format
Canadian Car & Foundry Harvard Mk.4, click to open in large format Canadian Car & Foundry Harvard Mk.4, click to open in large format Canadian Car & Foundry Harvard Mk.4, click to open in large format
North American T-6G Harvard, click to open in large format
1769
Canadian Car & Foundry Harvard Mk.4 - c/n CCF4-517
ex-Luftwaffe AA+078

Dados técnicos / Technical data
Motor / Engine:Pratt & Whitney R-1340-AN1
Potência / Power:550 hp
Envergadura / Span:12,80 mt
Comprimento / Length:8,99 mt
Altura / Height:3,58 mt
Superfície alar / Wing area:23,60 m2
Velocidade máxima / Maximum speed:205 mph / 330 km/h
Velocidade cruzeiro / Cruise speed:170 mph / 274 km/h
Raio de acção / Range:750 ml / 1.207 km
Tecto / Ceiling:21.500 ft / 6.555 mt
Peso vazio / Empty weight:4.158 lb / 1.886 kg
Peso máximo / Maximum weight:5.300 lb / 2.404 kg
